How far can I place a PMP from the tap-in point? (update)

Posted May 9th 2023

In an earlier blog post, we took a look at what happens when we monitor an E1/T1 line with an incorrectly placed monitor point. In this post, we repeat the measurements with a high-quality oscilloscope.

What are we doing?

When monitoring an E1/T1 line in the standard (ITU-T G.772) way, you have a tap-in point and resistors near the tap-in point:

G.772 monitor point schematic

There are two distances marked on the schematic:

From the tap-in point to the resistors: this distance is critical. The shorter, the better.

From the resistors to the monitoring equipment: we have a lot of leeway. Tens of metres is normal, up to 200 metres is possible.

A practical lab monitor point

We created this demonstration in our lab with a live E1 link, and varied the cable lengths to demonstrate various effects on the signal.

A monitored live link in the lab

In the photo, we've got a pocket oscilloscope. For this post, we replaced the pocket oscilloscope with a 5 giga-sample/s Teledyne digital storage oscilloscope, to get better measurements. (That's way more than we need for an E1 line.)

Live signal with a 0.5 metre tap-resistor distance

Here's what the live signal looks like in a correctly monitored setup, i.e. the one in the photo above.

a clean live E1 signal

The addition of the monitor point hasn't noticeably affected the live signal.

Live signal with a five metre tap-resistor distance

If we extend the tap-in to resistor distance to five metres, then the live signal becomes noticeably affected. The pulse has become slightly deformed, especially on the trailing edge. If the live link was extremely long haul, then we might be unlucky enough to cause it to go from "barely works" to "no longer reliable".

a slightly affected live E1 signal

Live signal with a 50 metre tap-resistor distance

If we keep going and extend the distance to 50 metres, the live signal is now affected to the point that it'll no longer work reliably. We can see an extra pulse after every real pulse:

a severely affected live E1 signal

Live signal on a long haul line

All of the above measurements were made with a short live E1 line, only a metre or two. For comparison, here's what an E1 looks like after 200 metres of cable. The pulses become shark-fin like. The receiving equipment expects this and has no trouble decoding the signal.

a live E1 signal after 200 metres of transmission

Permalink | Tags: GTH, telecom-signalling

Reading SS7 packets from a PCap file and replaying

Posted March 25th 2019

This is the second in a three-part series about different ways to replay signalling on an E1/T1 line in the lab. The three parts are:

  1. Replaying a bit-exact recording of an E1 timeslot.
  2. Reading SS7 packets from a .pcap file, re-create layer 2.
  3. Creating SS7 packets from scratch.

This post is about the second approach. It's particularly useful because we can use this technique to convert a SIGTRAN capture into an SS7 capture with MTP-3 and MTP-2. It's also satisfying because we can take packets full circle---we can play the packets from a PCap file and make a new PCap file with the same packets after they've passed through an E1 line. It assumes you have an E1 cable between P5 and P6, as illustrated in the previous post on this subject.

Approach #2: Read packets from a PCap file, replay on E1

Here's what the data-flow looks like:

data flow of PCap packets

1. The 'replay_mtp2' program reads SS7 packets from a PCap file.
2. The Corelatus box does bit-stuffing and inserts flags and FISUs.
3. After the signal goes out through an E1 cable and back in again, the Corelatus box recovers the SS7 packets.
4. 'save_to_pcap' saves the packets in PCapNG format.
5. Wireshark decodes MTP-3 and higher SS7 layers to display the packets.

The API command 'fr_layer' does step 2, it's described in the API manual. Here's what we do if we're using the C sample code:

    ./enable pcm5A
    ./enable pcm6A
    ./replay_mtp2 gth30 isup_load_gen.pcapng 5A 16

The PCap file with the signalling was made by a load generator. We can capture the signalling and make a new PCap file with the same packets, like this, in a separate window:

    ./save_to_pcap  -l 6A 16 gth.pcapng
    monitoring 6A:16 interface_id=0
    capturing packets, press ^C to abort
    saving to file gth.pcapng_00001
    Fri Mar 15 17:17:34 2019 signalling job m2mo0 changed state to 'in service'
    Fri Mar 15 17:17:48 2019 signalling job m2mo0 changed state to 'no signal units'

We can view both files in Wireshark and compare them. They'll contain the same packets, but with different relative timing, since 'replay_mtp2' just replays the packets as fast as possible.

Replaying other files

Wireshark has a collection of SS7 capture files, with all sorts of contents. They're all in the old 'classic' PCap format, so we have to convert them.


This file has three challenges. First, it's in the old PCap format. Second, the transport is SIGTRAN, so we have to extract the MTP-3 packets. Third, it uses a pre-RFC version of M3UA, so it's hard to see where the MTP-3 packets are. By inspecting the hex dump, we can see that MTP-3 starts 74 bytes into each packet, so we can use 'editcap' to make a new PCap file and then play it:

    > editcap -L -C 74 -T mtp3 isup.cap isup_fixed.pcap
    > ./replay_ss7 isup_fixed.pcap 5A 16
   Found link type 141 in capture file
   packet bytes replayed: 158. Sleeping to drain buffers.

Here's what the contents look like after a round-trip through the E1:

    >tshark -r mml.pcap_00001
    1      0.000        11522 ->        ISUP(ITU) 77 IAM (CIC 213)
    2      0.003        12163 -> 11522        ISUP(ITU) 21 CFN (CIC 213)
    3      0.005        12163 -> 11522        ISUP(ITU) 17 ACM (CIC 213)
    4      0.007        12163 -> 11522        ISUP(ITU) 17 ANM (CIC 213)
    5      0.010        11522 -> 12163        ISUP(ITU) 21 REL (CIC 213)
    6      0.012        12163 -> 11522        ISUP(ITU) 17 RLC (CIC 213)
    7      0.013              ->              MTP2 5 FISU

If you look at the output file more closely, you can see that the MTP-2 fields are faked; the sequence numbers don't increment. That's because the original data didn't have any sequence numbers in it. If we wanted to, we could extend 'replay_ss7' to generate realistic sequence numbers.

camel.pcap and camel2.pcap

These are more classic PCap files with SIGTRAN, but again we can convert them:

    > editcap -L -C 74 -T mtp3 camel.pcap camel_fixed.pcap
    > ./replay_ss7 camel_fixed.pcap 5A 16
   Found link type 141 in capture file
   packet bytes replayed: 559. Sleeping to drain buffers.

Viewing it in Wireshark requires "Signalling Connection Control Part"/"Protocol Preferences"/"Default Payload" to be set to TCAP. Same thing in 'tshark':

    >tshark -o "sccp.default_payload: tcap" -r mml.pcap_00001
    1      0.000           10 -> 100          Camel-v2 165 invoke initialDP
    2      0.027          100 -> 10           Camel-v2 217 invoke requestReportBCSMEvent invoke applyCharging invoke continue
    3      0.034           10 -> 100          TCAP 57 Continue otid(06f7) dtid(13b8)
    4      0.045           10 -> 100          TCAP 85 Continue otid(ec0f) dtid(0d7c)
    5      0.051          100 -> 10           TCAP 45 End dtid(ec0f)
    6      0.052              ->              MTP2 5 FISU


Same encoding as the 'camel' files. Contents:

    >tshark -r mml*
    1      0.000         1041 -> 8744         GSM MAP 149 invoke processUnstructuredSS-Request


    editcap -L -C 82 -T mtp3 ansi_map_ota.pcap ansi_fixed.pcap
    >tshark -r mml*   // after a round-trip through E1:
    1    0.000  18 -> 10  ANSI MAP 81 SMS Delivery Point to Point Invoke
    2    0.009  10 -> 18  ANSI MAP 69 SMS Delivery Point to Point ReturnResult
    3    0.020  18 -> 10  ANSI MAP 85 SMS Delivery Point to Point Invoke
    4    0.026  10 -> 18  ANSI MAP 45 SMS Delivery Point to Point ReturnResult
    5    0.036  18 -> 10  IS-683 81 SMS Delivery Point to Point Invoke


This file uses the Japanese variant of MTP-3. We need to tell Wireshark about that in the MTP-3 preferences:

    editcap -L -C 79 -T mtp3 japan_tcap_over_m2pa.pcap japan_fixed.pcap 2 4 6
    >  tshark -o "mtp3.heuristic_standard: TRUE" -r /tmp/mml.pcap*
    1      0.000         3003 -> 2730         SCCP (Japan) 32 SSA
    2      0.009         2730 -> 3003         TCAP 72 Begin otid(18250001)
    3      0.016         3003 -> 2730         GSM MAP 56 returnResultLast Unknown GSM-MAP opcode


This is the only SS7 capture on the Wireshark Sample Captures page which actually captured MTP-2. The hardware that captured it didn't save the FCS (Frame Check Sequence, a 16-bit CRC), so we need to tell 'replay_ss7' about that, otherwise the last two bytes of each packet will be chopped off:

    tshark -r ansi_tcap_over_itu_sccp_over_mtp3_over_mtp2.pcap ansi_fixed.pcap
    ./replay_ss7 -f ansi_fixed.pcap  5A 16
    >  tshark -r /tmp/mml.pcap*
    1      0.000         9283 -> 9444         ANSI MAP 150 Origination Request Invoke

Skipped files

I didn't bother with a few of the sample captures in the Wireshark wiki.
'bicc.cap' only contains one packet and it's not SS7.
'ansi_map_win.pcap' contains trucated packets.
'packlog-example.cap' contains a hex dump of a few packets, in a pinch we could convert it with 'text2pcap'.

Permalink | Tags: GTH, telecom-signalling

Replaying bit-exact E1/T1 timeslot recordings

Posted March 15th 2019

This note is about replaying signalling on an E1/T1 line in the lab, using an E1/T1 Messenger 3.0. We can connect two ports with a yellow crossover cable to make the Corelatus system talk to itself over an E1/T1 link.

looping an E1 from one port to another

Now that we've connected two E1 (or T1) ports, we can transmit and receive bytes. The next step is to make suitable bytes for transmission. Depending on what we have and what we want to do, we can use choose between three techniques:

  1. Replaying a bit-exact recording of an E1 timeslot.
  2. Reading SS7 packets from a .pcap file, re-create layer 2.
  3. Creating SS7 packets from scratch.

This post is about the first approach. I'll cover the other two in later articles.

Approach #1: bit-exact record-and-replay

We can record an E1 timeslot at an operator, take the file back to the lab and then replay it while working on the code to decode the SS7 packets we're interested in. Using a bit-exact recording lets you reproduce what happened in the operator's network. The relative packet timing will be the same. The sequence numbers will be identical. The packet payload will be identical.

All Corelatus hardware can record bit-exact timeslots, both on electrical E1 lines and on optical fiber (E1-on-SDH).

To replay, you need an E1/T1 Messenger 3.0, because it has transmit capabilities. If you have a E1/T1 Monitor 3.0, i.e. listen-only, you can temporarily turn it into a Messenger with a firmware update.

Here's what the data-flow looks like:

data flow of raw E1 bytes

The API commands needed for the recording and replaying, respectively, are 'recorder' and 'player'. They're described in the API manual, e.g. under 'new player'. We'll just use the C version of the sample code. If you prefer, you can use the Python or Perl version, or hack up your own code.

Here's how you can record a timeslot:

    ./record -l 1A 16 /tmp/signalling.raw
    started recording. Press ^C to end.
    0 1448 2896 4096 5544 6992 8192 9640 11088 ^C

The -l switch tells record that L1 is already set up, that way we avoid resetting it.

Back in the lab, we can replay the signalling file we made earlier. I've linked to a copy so you can try it. First, we need to turn the E1 ports on:

    ./enable pcm5A
    ./enable pcm6A

The LEDs in the ports will turn to green and the built-in webserver shows the ports as being in status OK. Next step is to replay the bits, i.e. step (1) on the data flow diagram:

    ./playback_file -l 5A 16 /tmp/2019_03_signalling.raw
    0 1600 3200 4800 6400 8000 wrote 8192 octets to the player
    all done

Most likely, you want to decode the signalling while playing it, this is step (4) on the diagram. You can do that in a separate window, like this:

    ./save_to_pcap  -l 6A 16 gth.pcapng
    monitoring 6A:16 interface_id=0
    capturing packets, press ^C to abort
    saving to file gth.pcapng_00001
    Fri Mar 15 17:17:34 2019 signalling job m2mo0 changed state to 'in service'
    Fri Mar 15 17:17:48 2019 signalling job m2mo0 changed state to 'no signal units'

When you've captured enough, hit control-C and view the PCap file with Wireshark, which is step (5) on the dataflow diagram. It'll look something like this:

Wireshark viewing the signalling

Permalink | Tags: GTH, telecom-signalling
